Diamond - G7/T7T-N
Gass koketopp i rustfritt stål AISI 304.
Stekeplate: 670x585 mm. 10 kW.

Gassoppvarming med brenner plassert i midten av brennkammeret.
Brennkammer termisk isolert med glassull.
Utløp for damp i bakkant.
Enkelt vedlikehold.

Flere cook line-moduler kan kobles sammen på rekke og/eller rygg mot rygg.

(BxDxH) mm: 700x700(730)x250/320
kcal/h (gas): 8600
kW: 10
Vekt: 68 kg
Fraktvolum: 0,3 m³

English:
Gas cooker hob -Top-
Hot plate, dimensions 670x585 mm (10kW).
Made of stainless steel AISI 304, adjustable cylinders.
Pressed top (15/10 mm).
Rear chimney in stainless steel AISI 304.
Cast iron fireback (10 mm) with removable central ring, gas heating by a burner positioned in the center of the combustion chamber.
Combustion chamber thermally insulated with glass wool.
Regulation by a gas valve, ignition by piezoelectric and safety by thermocouple, frontal accessibility allowing a very easy maintenance
